| INSTRUMENTATION CABLES-225/600 V
GRADE |
| REFFER. STANDARDS |
DIN VDE 0815, BS 5308,
IEC 60331, IEC 60332 |
| CONDUCTOR |
ELECTROLYTIC COPPER BARE/TINNED. |
| SIZES |
0.5 SQ.MM, 0.75 SQ.MM, 1.0 SQ.MM &
1.5 SQ.MM SOLID/STRANDED. |
| INSULATION |
A. FR PVC SUITABLE
FOR 70°C/85°C/125°C OPERATION. |
| |
B. MEDIUM/ HIGH DENSITY
POLYETHYLENE. |
| |
C. ZERO HALOGEN, VERY
LOW SMOKEPECIALLY FORMULATED POLYMER. |
| FORMATION |
MULTICORE/PAIR/TRIAD/QUAD. |
| SCREENING |
INDIVIDUAL PAIR/TRIAD OR/AND OVERALL/
PAIR/TRIAD. |
| |
A. ALLUMINIUM MYLAR/COPPER
FOIL WITH 100% COVERAGE AND 20% OVERLAP. |
| |
B. BRAIDING WITH 0.12/0.15
MM/0.2 MM/0.3 MM ELECTROLYTIC COPPER BARE/TINNED. |
| DRAIN WIRE |
ABC/ATC OF SUITABLE DIA ALONGWITH FOIL
SCREEN. |
| ARMOUR |
G.I. WIRE/STRIP AS PER IS 3975 (OPTIONAL). |
| INNER/OUTER SHEATH |
PVC/POLYETHYLENE/FRLS PVC/LOW HALOGEN
VERY LOW SMOKE SPECIALLY FORMULATED POLYMER. |
| SPECIAL TESTS |
CHARACTERISTIC IMPEDANCE, MUTUAL CAPACITANCE,
IMAGE ATTENUATION AND STATIC NOISE REJECTION LEVEL. |
| SQ.MM MULTICORE
SCREENED INSTRUMENTATION CABLE - UNARMOURED |
| Description |
Cond. Size |
Ins. Thickness |
Alum.
Mylar |
Thickness of Sheath |
External Diameter |
| mm |
mm |
mm |
mm |
mm |
| 2Cx1.0 SQ.MM |
7/0.42 |
0.60 |
0.062 |
1.20 |
9.80 |
| 4Cx1.0 SQ.MM |
7/0.42 |
0.60 |
0.062 |
1.20 |
11.00 |
| 7Cx1.0 SQ.MM |
7/0.42 |
0.60 |
0.062 |
1.20 |
12.80 |
| 10Cx1.0 SQ.MM |
7/0.42 |
0.60 |
0.062 |
1.20 |
16.50 |
| 16Cx1.0 SQ.MM |
7/0.42 |
0.60 |
0.062 |
1.20 |
18.50 |
| 19Cx1.0 SQ.MM |
7/0.42 |
0.60 |
0.062 |
1.20 |
19.50 |
| SQ.MM MULTICORE
SCREENED INSTRUMENTATION CABLE - UNARMOURED |
| Description |
Cond.
Size |
Ins.
Thickness |
Alum.
Mylar |
Thickness
of Sheath |
External
Diameter |
| mm |
mm |
mm |
mm |
mm |
| 2Cx1.5 SQ.MM |
7/0.52 |
0.60 |
0.062 |
1.20 |
10.50 |
| 4Cx1.5 SQ.MM |
7/0.52 |
0.60 |
0.062 |
1.20 |
12.00 |
| 7Cx1.5 SQ.MM |
7/0.52 |
0.60 |
0.062 |
1.20 |
14.80 |
| 10Cx1.5 SQ.MM |
7/0.52 |
0.60 |
0.062 |
1.20 |
17.50 |
| 16Cx1.5 SQ.MM |
7/0.52 |
0.60 |
0.062 |
1.20 |
19.50 |
| 19Cx1.5 SQ.MM |
7/0.52 |
0.60 |
0.062 |
1.20 |
20.50 |
| |
